Introducing the all new Bradcot Modul-AiR Motor, our exclusive extendible, inflatable 330cm wide Motor Home Awning.

This model is made to suit Motor Homes with an awning rail height of between 266cm to 280cm. Four further models are available depending on the awning rail height of your Motor Home, see Modul-Air Motor, "H", "HX", "H2X" and "H3X

Modul-AiR Motor "HX" Inflatable Motorhome Awning (Height 266-280cm) Details

This exciting addition to the acclaimed Bradcot Awning range has been in development for several years. As with all Bradcot models, we have avoided sourcing inferior materials from the Far East and use only the highest quality "Ten Cate" European fabrics.

The MODUL-AiR's ingenious "frame" features an inflation bladder using the best available TPU of a quality and thickness far in advance of any currently used in the 'inflatable awning' market across the UK and Europe. Its unique design allows filling from one inflation point only (more are fitted to assist with deflation) and, if used in conjunction with our 'E-Pump', can be fully inflated in under 4 minutes! Together with our UK-manufactured Marine Grade inflation valves, this high-specification product ensures that you can clock up countless air miles with a long and trouble-free life for your inflatable awning.

Modul-AiR Motor "HX" Inflatable Motorhome Awning (Height 266-280cm) Details

Modul-AiR Motor "HX" Inflatable Motorhome Awning (Height 266-280cm) Specification

Feature

Modul-AiR Motor "HX" Inflatable Motorhome Awning (Height 266-280cm)

  • Roof
  • Tencate Coated Polyester Roof
  • Walls
  • Removable front and side panels, and ventilated side mesh windows
  • Size
  • Rail length in CM* 3.30mtrs
  • Rail height in CM* 2.66mtrs to 2.80mtrs
  • Projection in CM* 2.60mtrs
  • Length (Ground floor) in CM* 3.30mtrs
  • Extendable Modul-AiR design (patent pending no. 1102970.9)
  • 2m internal roof height at front
  • Warranty
  • 3 year manufacturer’s warranty (Touring use only)
  • 5 Year UV Degradation Warranty (Touring use only
  • Optional Extras
  • 12v Electric pump (6mtr length cable-crocodile clip only to leisure battery or car battery) inflates 260 base in approx. 3min & 330 base in approx. 4min(Cost Option)
  • AiR annexe available – right hand facing only (cost option)

Feature

Modul-AiR Motor "HX" Inflatable Motorhome Awning (Height 266-280cm)

  • Side Doors
  • Side ventilation with clear zipped covers
  • Easy glide curtain rods
  • Veranda Effect
  • Air Inflation Technology
  • Genuine TenCate roof/wall awning fabric
  • Robust 450 micron fully integrated TPU bladder system
  • 140mm diameter main beams (smooth finished)
  • Single inflation point (valve on each main leg to aid deflation only)
  • Back poles and storm straps as standard
  • TenCate touring all season polyester wall and roof material
  • Removable front and side panels
  • Ventilated side mesh windows x2
  • Easy glide curtain rods
  • Bradcot’s unique MAPS (Moveable, Adjustable, Pegging System)
  • Storm Straps
